Color menu display interface
Intelligent bus control mode; maximum 255（64/128/192/255 can choose） addressable points per loop, maximum 1 loop, maximum 12 fire display panels
Glass fuse per loop
Black box function
Wave filtering style output: loop output, power output, sounder strobe output, fire relay output
Design loop protocol yourself
Wall-mounted structure, compact and exquisite
Language support: simplified Chinese, English (America), English (England)
Technical Specifications
Mains supply:
AC220V (3A)
Voltage range: +10%～-15%
Backup battery:
DC24V (6A)
12V/12AH sealed lead acid battery
LCD screen size: 4.3-inch color LCD screen
Operating Environment:
Temperature: 0°C～+40°C
Relative Humidity: ≤95%, non-condensing
Capacity: 255 addressable points
Dimension (L×W×H): 320mm×120mm×400mm
